CYFLWYNIAD:
Mae'r Toppo Marco Linear wedi dod yn oleuwr llinellol cynyddol boblogaidd ar y farchnad. Mae'r luminaire LED amlbwrpas hwn yn cynnwys gosodiadau CCT a watedd y gellir eu haddasu, gan ddarparu hyblygrwydd ar gyfer amrywiaeth o anghenion goleuo. Gellir gosod y Marco Linear fel luminaire cilfachog neu fel golau llinol pendant LED, diolch i ystod o ategolion mowntio fel citiau hongian a thraciau. Mae ar gael mewn gorffeniadau gwyn, llwyd a du, gan ganiatáu iddo gael ei integreiddio'n ddi-dor i amrywiaeth o gynlluniau dylunio. Yn ogystal, mae'r Golau Proffil Llinellol Marco ar gael mewn opsiynau uplight a downlight, sy'n galluogi cwsmeriaid i deilwra datrysiad goleuo i'w hanghenion cymhwysiad penodol.
|
Tryledwr |
UGR |
Cod Gorchymyn |
Pŵer â Gradd |
LM/W |
Lumen |
Dimensiwn Cynnyrch |
Swyddogaeth |
|
Prismatig |
UGR<22 |
LL400-04B-AT1-40F01 |
20-40W |
Teip.130 |
Typ.2600-5200 |
L1150xW60xH80 |
YMLAEN-I FFWRDD |
|
Prismatig |
UGR<22 |
LL400-04B-AT1-40V01 |
20-40W |
Teip.130 |
Typ.2600-5200 |
L1150xW60xH80 |
PWM ( Ar gyfer MS ) |
|
Prismatig |
UGR<22 |
LL400-04B-AT1-40D01 |
20-40W |
Teip.130 |
Typ.2600-5200 |
L1150xW60xH80 |
DALI |
|
Prismatig |
UGR<22 |
LL400-05B-AT1-50F01 |
30-50W |
Teip.130 |
Typ.3900-6500 |
L1437xW60xH80 |
YMLAEN-I FFWRDD |
|
Prismatig |
UGR<22 |
LL400-05B-AT1-50V01 |
30-50W |
Teip.130 |
Typ.3900-6500 |
L1437xW60xH80 |
PWM ( Ar gyfer MS ) |
|
Prismatig |
UGR<22 |
LL400-05B-AT1-50D01 |
30-50W |
Teip.130 |
Typ.3900-6500 |
L1437xW60xH80 |
DALI |
|
Prismatig |
UGR<22 |
LL400-06B-AT1-60F01 |
40-60W |
Teip.130 |
Typ.5200-7800 |
L1723xW60xH80 |
YMLAEN-I FFWRDD |
|
Prismatig |
UGR<22 |
LL400-06B-AT1-60V01 |
40-60W |
Teip.130 |
Typ.5200-7800 |
L1723xW60xH80 |
PWM ( Ar gyfer MS ) |
|
Prismatig |
UGR<22 |
LL400-06B-AT1-60D01 |
40-60W |
Teip.130 |
Typ.5200-7800 |
L1723xW60xH80 |
DALI |
|
Opal |
/ |
LL410-04B-AT1-40F01 |
20-40W |
Typ.150 |
Typ.3000-6000 |
L1150xW60xH80 |
YMLAEN-I FFWRDD |
|
Opal |
/ |
LL410-04B-AT1-40V01 |
20-40W |
Typ.150 |
Typ.3000-6000 |
L1150xW60xH80 |
PWM ( Ar gyfer MS ) |
|
Opal |
/ |
LL410-04B-AT1-40D01 |
20-40W |
Typ.150 |
Typ.3000-6000 |
L1150xW60xH80 |
DALI |
|
Opal |
/ |
LL410-05B-AT1-50F01 |
30-50W |
Typ.150 |
Typ.3000-6000 |
L1437xW60xH80 |
YMLAEN-I FFWRDD |
|
Opal |
/ |
LL410-05B-AT1-50V01 |
30-50W |
Typ.150 |
Typ.3000-6000 |
L1437xW60xH80 |
PWM ( Ar gyfer MS ) |
|
Opal |
/ |
LL410-05B-AT1-50D01 |
30-50W |
Typ.150 |
Typ.3000-6000 |
L1437xW60xH80 |
DALI |
|
Opal |
/ |
LL410-06B-AT1-60F01 |
40-60W |
Typ.150 |
Typ.3000-6000 |
L1723xW60xH80 |
YMLAEN-I FFWRDD |
|
Opal |
/ |
LL410-06B-AT1-60V01 |
40-60W |
Typ.150 |
Typ.3000-6000 |
L1723xW60xH80 |
PWM ( Ar gyfer MS ) |
|
Opal |
/ |
LL410-06B-AT1-60D01 |
40-60W |
Typ.150 |
Typ.3000-6000 |
L1723xW60xH80 |
DALI |
|
Adlewyrchydd |
UGR<17 |
LL420-04B-RT1-40F01 |
20-40W |
Typ.150 |
Typ.3000-6000 |
L1150xW60xH80 |
YMLAEN-I FFWRDD |
|
Adlewyrchydd |
UGR<17 |
LL420-04B-RT1-40V01 |
20-40W |
Typ.150 |
Typ.3000-6000 |
L1150xW60xH80 |
PWM ( Ar gyfer MS ) |
|
Adlewyrchydd |
UGR<17 |
LL420-04B-RT1-40D01 |
20-40W |
Typ.150 |
Typ.3000-6000 |
L1150xW60xH80 |
DALI |
|
Adlewyrchydd |
UGR<17 |
LL420-05B-RT1-50F01 |
30-50W |
Typ.150 |
Typ.4500-7500 |
L1437xW60xH80 |
YMLAEN-I FFWRDD |
|
Adlewyrchydd |
UGR<17 |
LL420-05B-RT1-50V01 |
30-50W |
Typ.150 |
Typ.4500-7500 |
L1437xW60xH80 |
PWM ( Ar gyfer MS ) |
|
Adlewyrchydd |
UGR<17 |
LL420-05B-RT1-50D01 |
30-50W |
Typ.150 |
Typ.4500-7500 |
L1437xW60xH80 |
DALI |
|
Adlewyrchydd |
UGR<17 |
LL420-06B-RT1-60F01 |
40-60W |
Typ.150 |
Typ.6000-9000 |
L1723xW60xH80 |
YMLAEN-I FFWRDD |
|
Adlewyrchydd |
UGR<17 |
LL420-06B-RT1-60V01 |
40-60W |
Typ.150 |
Typ.6000-9000 |
L1723xW60xH80 |
PWM ( Ar gyfer MS ) |
|
Adlewyrchydd |
UGR<17 |
LL420-06B-RT1-60D01 |
40-60W |
Typ.150 |
Typ.6000-9000 |
L1723xW60xH80 |
DALI |
|
Lens |
UGR<14 |
LL430-04B-CT1-40F01 |
20-40W |
Typ.160 |
Typ.3200-6400 |
L1150xW60xH80 |
YMLAEN-I FFWRDD |
|
Lens |
UGR<14 |
LL430-04B-CT1-40V01 |
20-40W |
Typ.160 |
Typ.3200-6400 |
L1150xW60xH80 |
PWM ( Ar gyfer MS ) |
|
Lens |
UGR<14 |
LL430-04B-CT1-40D01 |
20-40W |
Typ.160 |
Typ.3200-6400 |
L1150xW60xH80 |
DALI |
|
Lens |
UGR<14 |
LL430-05B-CT1-50F01 |
30-50W |
Typ.160 |
Typ.4800-8000 |
L1437xW60xH80 |
YMLAEN-I FFWRDD |
|
Lens |
UGR<14 |
LL430-05B-CT1-50V01 |
30-50W |
Typ.160 |
Typ.4800-8000 |
L1437xW60xH80 |
PWM ( Ar gyfer MS ) |
|
Lens |
UGR<14 |
LL430-05B-CT1-50D01 |
30-50W |
Typ.160 |
Typ.4800-8000 |
L1437xW60xH80 |
DALI |
|
Lens |
UGR<14 |
LL430-06B-CT1-60F01 |
40-60W |
Typ.160 |
Typ.6400-9600 |
L1723xW60xH80 |
YMLAEN-I FFWRDD |
|
Lens |
UGR<14 |
LL430-06B-CT1-60V01 |
40-60W |
Typ.160 |
Typ.6400-9600 |
L1723xW60xH80 |
PWM ( Ar gyfer MS ) |
|
Lens |
UGR<14 |
LL430-06B-CT1-60D01 |
40-60W |
Typ.160 |
Typ.6400-9600 |
L1723xW60xH80 |
DALI |
